Description
9203C-R Pump
Pentair Hypro 9203C & 9203S Series Centrifugal Pumps
This pedestal mount, cast iron and stainless steel, direct drive centrifugal pump achieves up to 140 gpm (530 lpm) and 170 psi (11.7 bar). The series includes models 9203C, 9203S, 9203C-R, and 9203S-R with NPT or 220 x 200 universal flange.
- Pedestal mount, direct drive
- 220 x 200 Universal flange available (U)
- Pump shaft rotation: Counter clockwise when looking at the shaft end; 9203C-R is clockwise
- Life Guard seals are the industry standard on OEM equipment
- Stainless steel models now available with universal flange
Housing Material: Cast Iron
| Item # | Product | Max LPM | Max GPM | Max PSI | Max BAR | Seal Material | Shaft Output |
|---|---|---|---|---|---|---|---|
|
9203C
|
9203C and 9203S Series
|
530
|
140
|
170
|
11.7
|
Viton ® /ceramic standard; Life Guard silicon carbide (B) available
|
5⁄8" (15.9 mm) solid shaft
|
|
9203C-R
|
9203C and 9203S Series
|
530
|
140
|
170
|
11.7
|
Viton ® /ceramic standard; Life Guard silicon carbide (B) available
|
5⁄8" (15.9 mm) solid shaft
|
